150# Red Rubber Full Face Gasket & Bolt Kit
Overview:
This red rubber full face gasket and bolt kit is a complete flange accessory assembly designed for joining two ANSI Class 150 flanges. The package includes red SBR rubber gasket plus zinc-plated carbon steel nuts and bolts, delivering an all-in-one sealing solution for commercial piping connections.
Available in a wide size range from 1/2" to 18". The gasket is made of styrene-butadiene rubber (SBR) with Shore A hardness of 75 ±5, offered in full face or ring style. It complies with ASME B16.21 and dimensions follow ASME B16.5. Rated for maximum working pressure of 200 psi and operating temperature from -20°F to 170°F.
Ideal for commercial pipe flanged joints, it ensures dependable flange sealing and simplifies procurement and site installation.
Key Features:
- Size Range: 1/2" ~ 18"
- Complete flange assembly: red SBR rubber gasket + zinc plated carbon steel nuts & bolts
- For ANSI Class 150 flanges
- Gasket material: styrene-butadiene rubber (SBR), red colour
- Durometer Hardness: Shore A 75 ±5
- Optional gasket types: full face and ring style
- Gasket conforms to ASME B16.21; dimensions comply with ASME B16.5
- Max working pressure: 200 psi
- Working temperature range: -20°F ~ 170°F
- Gasket thickness: 0.125 in
- Carbon steel fasteners with zinc plating for anti-corrosion performance
- Commercial grade assembly for flanged pipe joint sealing
- Pre-packaged all-in-one kit to meet diversified project requirements
